Ebara DW MA Dirty Water Pump Threaded

Ebara DW MA Range – Automatic Stainless Steel Submersible Drainage Pumps (With Float Switch)

The Ebara DW MA Range combines power, reliability, and convenience in a durable stainless steel submersible pump series designed for clean and slightly dirty water.

Constructed entirely from AISI 304 stainless steel, the DW MA models are equipped with an automatic float switch that enables hands-free start/stop control. Perfect for basements, sumps, tanks, or any installation where water levels fluctuate and automatic operation is preferred.

✅ Key Features

• Automatic float switch for level-controlled operation

• Corrosion-resistant stainless steel design (AISI 304)

• Semi-open impeller handles soft solids up to 10 mm

• Double mechanical seal in oil bath for durability

• Built-in thermal overload protection

• Plug-and-play installation – pre-wired float and 10 m cable

• Compact and lightweight for easy setup and maintenance

📊 Technical Specifications

All models: 230 V · 50 Hz single-phase · Max liquid temp 50 °C · Max immersion 10 m · 10 m cable length · IP68 protection.

🛠 Ideal Applications

• Automatic basement, cellar, or garage drainage

• Tanks, reservoirs, or sumps with fluctuating water levels

• Irrigation and rainwater reuse systems

• Light commercial and construction drainage

• General clean- and grey-water pumping

⚙️ Benefits

• Hands-free automatic operation with integrated float

• Reliable stainless-steel build for long life and corrosion resistance

• Quiet, efficient performance

• Low maintenance, simple installation

• Choice of three power ratings (0.75 – 1.5 kW) to match every duty requirement

🛠️ Need sizing help or maintenance guidance?

Our Henry Pumps specialists are here to help — from installation assistance to spare parts and servicing.

📞 0333 050 3748 | ✉️ sales@henrypumps.co.uk
