ESPA Drainex 200 Sewage Vortex Pump

The Drainex 200 models, manufactured by ESPA Pumps are a range of submersible sewage pumps including a set-back vortex impeller designed for the drainage of both clear and dirty waste water with a solids handling capability of 45mm.  Engineered out of a mixture of both cast-iron stainless steel 304, the ESPA Drainex 200 range are a tough pump that is particularly suited to a range of drainage and commercial waste water jobs.

Applications:

Drainage of dirty and sewage waste water - maximum solids particle size of 45mm.
Septic tanks.
Wet wells, sewage systems etc.

The motor shaft is constructed from stainless steel AISI 304 and the pump includes a double mechanical seal and o-rings in NBR.

Motor:

IP68 protection.
Class F insulation.
Built-in thermal protection and capacitor - 1phs.
Oil filled motor.

Very efficient to operate with motors rated at only 1.1kW, 1.4kW and 1.6kW.

Please check with us prior to ordering as these models are not always in stock.

The Drainex 200 models are supplied with a 50mm threaded outlet suitable for hose connection or guide rail installation.  All Drainex 200 pumps are available in 230v have the option of being either manual or fully automatic with float switch.  The Drainex 200 from ESPA is also available in 400v.
