Flygt C3045 Sewage Pump

FLYGT C3045 WASTEWATER CHANNEL IMPELLER PUMP

The Flygt C3045 are equipped with a shrouded, single or multi vane-vane impeller that runs in a volute.  The shape and size of the impeller is designed to minimise clogging, which makes the Flygt C3045 ideal for waste water applications.  The Flygt C3045 truly is a reliable submersible pump for residential, commercial and light industrial applications.

Over the years, the classic C-pump has proven to be both reliable and robust. The Flygt C-range covers a wide capacity range and is designed to handle different types of media.

Please be advised that some of these pumps are ordered in direct from the factory and are on a short lead time.  Please check with us prior to ordering.

The Flygt C3045 in this section features a shrouded single-vane impeller. It has excellent flow passing properties that reduce the risk for clogging in the impeller channel. A narrow gap between the interchangeable wear rings ensures high efficiency.

ROBUST AND RELIABLE DESIGN

    Short shaft overhang. Reduces shaft deflection while increasing seal and bearing life.
    Motor designed for submersible use. Heat is concentrated to the stator core for improved cooling properties
    Martensitic stainless steel shaft gives maximum strength and corrosive resistance
    Double mechanical seal system. Two sets of mechanical shaft seals work independently to provide double security. Available in Tungsten carbide (WCCR) or Silicone carbide (SiC) depending on pumped media.
    Griplock seal system. Secure locking of the shaft, no rubber friction, no grub screws and no shaft damage.
    Motor cable SUBCAB® developed especially for submersible use

Product Features

    High efficiency
    Excellent flow passing properties
    Motors equipped with high power density
    Robust and reliable

Built to last.  That is exactly what you would expect from Flygt pumps.  These submersible pumps are ideal for small-scale sewage transport and even groundwater drainage in locations such as private dwellings, work shops or restaurants.  These pumps could not be simpler to install, available in either permanent P type installation or the free standing S type, they can simply be lowered into position and set to work.

Twin oil bathed mechanical seals ensure both reliability and longevity.  The oil chamber is filled with an environmentally friendly white oil that is free from aromatic hydrocarbons and is approved by the FDA for use in the food industry.  The motor is designed specifically for the Flygt pump ensuring years of trouble free operation.  The Flygt C3045 is made even more reliable being engineered from a cast-iron shell.

The CP pumps in this section come with a guide claw fitted to the pump and are designed for permanent installations where twin guide rails will be used.

The CS pumps in this section is a portable option supplied on a free standing base plate with discharge outlet suitable for a hose connection.

Full product data sheet can be viewed by clicking here.
