Information
Robust, compact and highly efficient, the Flygt 3102 series is available in a variety of power ratings from as low as 3.1kW up to 4.5kW. With an 100mm and 150mm discharge outlets, this pump range is available with Adaptive N, Grinder or Vortex style pump ends and come complete with 10 metre SUBCAB power cable.
The Flygt 3102 range featured on this page showcase the state of the art Adaptive N style pump end which is available in either hard-iron, grey iron or stainless steel impellers.
If you are looking for a small pump that is simple to install and just keeps on working then look no further. The waste water experts at Flygt have developed their most complete range, now available with clog free adaptive N style pump ends means you can rest assured of reliable and trouble free operation.
Flygt 3102 N pumps consistently take on the toughest waste water applications and get the job done, time after time. Every component is developed to sustain high efficiency and thanks to the adaptive N style pump end these pumps reduce your energy bill and maintenance requirements.
Most solid objects entering the pump end will pass through the impeller between the impeller vanes. If an object gets caught along the leading edge of a vane, it will slide along the leading edge of the vane towards the perimeter of the inlet. Due to mechanical self-cleansing of the Flygt 3102, this allows for a sludge concentration of up to 8% to be easily pumped.
This self-cleaning pump features innovative functions that make it the best choice for a broad range of applications. The modular hydraulic design enables you to tailor the hydraulics to meet the requirements of virtually any application.
Replaceable wear ring in two materials, gray iron or Hard IronTM, for different operation conditions
Hardened gray iron impeller for typical wastewater applications
Hard Iron impeller for abrasive and corrosive applications
Stainless steel impeller for special applications that require duplex stainless steel
Short shaft overhang reduces shaft deflection and increases seal and bearing life
Motor designed for submersible use. Heat is concentrated to the stator core for improved cooling properties.
Griplock seal system secures locking to the shaft, no rubber friction, no grub screws and no shaft damage
Motor cable SUBCAB ® specially developed for submersible use.
The Flygt 3102 range featured on this page showcase the state of the art Adaptive N style pump end which is available in either hard-iron, grey iron or stainless steel impellers.
If you are looking for a small pump that is simple to install and just keeps on working then look no further. The waste water experts at Flygt have developed their most complete range, now available with clog free adaptive N style pump ends means you can rest assured of reliable and trouble free operation.
Flygt 3102 N pumps consistently take on the toughest waste water applications and get the job done, time after time. Every component is developed to sustain high efficiency and thanks to the adaptive N style pump end these pumps reduce your energy bill and maintenance requirements.
Most solid objects entering the pump end will pass through the impeller between the impeller vanes. If an object gets caught along the leading edge of a vane, it will slide along the leading edge of the vane towards the perimeter of the inlet. Due to mechanical self-cleansing of the Flygt 3102, this allows for a sludge concentration of up to 8% to be easily pumped.
This self-cleaning pump features innovative functions that make it the best choice for a broad range of applications. The modular hydraulic design enables you to tailor the hydraulics to meet the requirements of virtually any application.
Replaceable wear ring in two materials, gray iron or Hard IronTM, for different operation conditions
Hardened gray iron impeller for typical wastewater applications
Hard Iron impeller for abrasive and corrosive applications
Stainless steel impeller for special applications that require duplex stainless steel
Short shaft overhang reduces shaft deflection and increases seal and bearing life
Motor designed for submersible use. Heat is concentrated to the stator core for improved cooling properties.
Griplock seal system secures locking to the shaft, no rubber friction, no grub screws and no shaft damage
Motor cable SUBCAB ® specially developed for submersible use.
The Flygt 3000 series wastewater pump range is designed for use across the full spectrum of fluid handling. These versatile pumps can be used for everything from pumping sewage and sludge to process and raw-water handling, as well as irrigation, other municipal applications and the full breadth of uses within aquaculture and agriculture.
Other models are available within this range. Please telephone us to discuss your exact requirements in more detail. Please note that a short lead time of a few days could apply to this product range.
Full technical data sheet for our small Flygt waste water pumps can be viewed by clicking here.
Full manufacturers specification sheet for the Flygt N type pumps can be viewed by clicking here.
Specifications
-
Condition:New
-
Weight:112kg
