Stainless Steel Wafer Type Swing Check Valve

Stainless Steel Swing Check Valve – Wafer Type (A Range)

The Stainless Steel Wafer Swing Check Valve offers a compact, efficient, and corrosion-resistant solution for preventing backflow in pipelines. Designed to operate automatically with line pressure, this non-return valve is constructed from durable 304 stainless steel, making it ideal for aggressive or corrosive media in processing, water treatment, and industrial applications.

Its wafer-style body ensures easy installation between flanges without the need for extensive pipework modification, and its EPDM soft seat provides excellent sealing with minimal cracking pressure—ensuring low resistance to flow while reliably stopping reverse flow.

Key Features:

✅ Stainless Steel Body (304) – Exceptional corrosion resistance
✅ Wafer Pattern – Compact, lightweight, and easy to install between PN16 flanges
✅ EPDM Seat – Resilient sealing performance with excellent chemical resistance
✅ Low Cracking Pressure – Promotes efficient flow while preventing backflow
✅ Spring-Assisted Closure – Quick shut-off to protect upstream components
✅ Bi-directional Flow Design – Suitable for horizontal and vertical installations
✅ Working Pressure: PN25 (25 bar max)
✅ Temperature Range: -10°C to +150°C

Technical Specifications:

• Body Material: CF8M Stainless Steel (AISI 316)

• Disc Material: Stainless Steel

• Seat Material: EPDM

• Design: Wafer Pattern (compact)

• Max Working Pressure: 25 bar

• Temperature Range: -10°C to +150°C

• End Connection: Designed to fit between PN16 flanges

• Sizes Available: DN50 to DN300

Common Applications:

• Chemical and Petrochemical Pipelines

• Water and Wastewater Systems

• Marine and Offshore Installations

• Food & Beverage and Pharmaceutical Plants

• General Industrial Processing

Compact Backflow Prevention with Corrosion Resistance Built In

The Henry Pumps Stainless Steel Wafer Check Valve provides reliable non-return performance in harsh environments where durability and space-saving installation are essential. With quick, spring-assisted closing and a low maintenance design, it’s the ideal check valve for critical applications that demand long service life and efficiency.

📞 Need help specifying check valves for your system?
Speak with the Henry Pumps team today—we’re happy to advise on sizing, compatibility, and installation.

📩 sales@henrypumps.co.uk
📞 0333 050 3748
